Nanotechnology
Nanotechnology is defined as the systematic manipulation, fabrication, or modification of structures, systems, materials, or components in the range of atomic or molecular dimensions with up to nanoscale dimensions between 1 nm and 100 nm (1 nm= 10−9 m). It is referred to as the bottom up method in which materials are created using chemical processes at nanoscale size.

Navigate this technology
La ciencia detrás de Sol-Gel
Comprender los mecanismos moleculares que permiten los revestimientos funcionales ultrafinos.
Sol-Gel
Sol-gel processing transforms liquid precursors into solid networks through controlled chemical reactions. Silicon alkoxides undergo hydrolysis and polycondensation, forming three-dimensional siloxane (Si-O-Si) networks at ambient conditions.
The process enables precise control over film thickness, porosity, and surface chemistry at nanoscale, allowing the incorporation of functionalities like easy to clean, anti-corrosion, barrier effects without compromising structural integrity.
Principales ventajas científicas
-
Low-temperature, low-stress processing on any substrate
-
Molecularly uniform, conformal films on complex 3D geometries
-
Precise thickness (nm→µm) and porosity control (dense→mesoporous)
-
Strong chemical adhesion to metals, glass, and polymers
-
Excellent moisture and oxygen barrier → improved corrosion resistance
-
Tunable optics (AR, transparency, index) and smooth surfaces
-
Tough, scratch-resistant, thermally/chemically stable coatings
-
Easy to load with functional precursors (self-healing, catalytic, sensing, easy to clean)

La ciencia detrás de Sol-Gel
Comprender los mecanismos moleculares que permiten los revestimientos funcionales ultrafinos.
Nano Titanium Dioxide Coatings
The sol-gel method is commonly used as a direct process to create titanium dioxide coatings on various surfaces. After the preparation of the sol, the solution can be directly applied to the surface. The nanoparticles are dried and cured, and the resulting titanium dioxide coating exhibits several desirable properties, including high transparency, photo-activity, and good adhesion to the substrate. It is commonly used in applications such as self-cleaning, air purifying, and antimicrobial coatings. The sol-gel method provides an effective way to produce titanium dioxide coatings with precise control over their thickness and properties.
Nano titanium dioxide photocatalyst
Nano titanium dioxide photocatalysis is a process in which organic matter is decomposed under light radiation using nano-sized titanium dioxide particles as a catalyst. The mechanism of this process can be described as follows:
- Absorption of light: When light is absorbed by the nano titanium dioxide particles, electrons in the valence band are excited to the conduction band, leaving behind electron holes in the valence band.
- Formation of reactive species: The excited electrons and electron holes can react with adsorbed oxygen and water molecules on the surface of the titanium dioxide particles to generate highly reactive species, such as hydroxyl radicals (•OH) and superoxide ions (•O2-).
- Adsorption of organic matter: The highly reactive species generated in the second step can react with organic matter adsorbed on the surface of the titanium dioxide particles or in the surrounding solution, breaking it down into smaller, harmless molecules such as CO2 and H2O.
- Regeneration of titanium dioxide: Finally, the electron holes left behind in the valence band can react with the adsorbed hydroxyl ions to form hydroxyl radicals, which in turn can react with the excited electrons to regenerate the original titanium dioxide particles.

La ciencia detrás de Sol-Gel
Comprender los mecanismos moleculares que permiten los revestimientos funcionales ultrafinos.
Ceramic Coatings
Preceramic precursors are used to generate ceramic coatings with pencil hardness of 9H. These thin superhard coatings can be applied on any surface like glass, metal, plastic or painted material. Ceramic coating excell in mechanical, weather and chemical resistance at DFT of less than 5 microns.
Super Hard Coating Properties
- Super hard coatings
- Antigraffiti and easy to clean effect
- Corrosion resistant
- Barrier effect
- PFAS replacment
- Excellent refurbish effect on weathered surfaces


Smart functional coatings
EXOCOAT™ nanotechnology: Self-cleaning, antimicrobial, anti-corrosion properties
Mode of action
From molecular precursors to functional nanocoatings in controlled steps.
Silicon alkoxides mixed with water, alcohol, and catalysts under controlled pH to initiate hydrolysis reactions and ensure reproducible film properties.
Hydrolysis creates reactive silanol groups, leading to polycondensation and formation of stable colloidal sol with controlled viscosity.
Sol applied via dip-coating, spin-coating, or spray methods, forming uniform wet film on substrate surface with precise thickness control.
Technology applications
Sol-Gel nanotechnology creates tangible value across industries, delivering measurable performance improvements







Automotive
EXOCOAT™ Ceramic+ forms a durable ceramic layer that shields car lacquer from UV rays, scratches, and chemical damage, preserving a glossy finish over time. Its ultra-smooth surface repels dirt and brake dust, making rims significantly easier to clean and maintain. Meanwhile, EXOCOAT™ ClearView enhances glass surfaces with extreme hydrophobicity, causing water to bead and roll off instantly, thus enabling wiperless driving in rain. Both coatings offer long-lasting protection and reduce the need for frequent cleaning, combining performance with convenience. Together, they elevate vehicle care to a new level of efficiency and style.
Architecture
EXOCOAT™ 151 is a high-performance photocatalytic coating that keeps surfaces like heritage buildings, rendered walls, solar panels, and facades clean by harnessing light to break down organic pollutants and grime. Its nano-titanium oxide formula produces a superhydrophilic surface that lets rainwater rinse away dirt without streaks, while also breaking down airborne contaminants like VOCs and NOx under visible light. This helps lower maintenance needs and protects the surface over time.
OEM
EXOCOAT™ coatings can be seamlessly integrated into OEM processes under controlled conditions to provide long-term protection for components and surfaces. By forming a thin, uniform layer, they shield parts from aging effects such as UV degradation and oxidation. Their advanced chemical resistance helps prevent corrosion, even in harsh environments or during extended use. The coatings also enhance mechanical durability, reducing wear and surface damage from friction or impact. This results in extended product life, reduced maintenance, and improved performance across automotive, industrial, and consumer applications.
Glass care
Glass surfaces are constantly exposed to water, dirt, and environmental stress, which can lead to staining, reduced clarity, and frequent cleaning. Protecting glass with a high-performance coating like EXOCOAT™ ClearView not only preserves its appearance but also enhances durability and ease of maintenance.
EXOCOAT™ ClearView is a high-performance, transparent ceramic coating designed to elevate glass care with exceptional hydrophobic and oleophobic properties. It instantly transforms glass surfaces such as windows, mirrors and shower enclosures into water-repellent, easy-to-clean surfaces with contact angles close to 120°. The coating chemically bonds to the glass, forming a durable layer that resists UV damage, household chemicals, and mechanical wear, ensuring long-lasting clarity and protection. Ideal for both residential and marine environments, ClearView reduces calcium deposits on bathroom ceramics and yacht glass, simplifying maintenance. With its invisible finish and proven durability, EXOCOAT™ ClearView sets a new standard in glass surface protection.
Aviation
Sol-gel coatings have emerged as eco-friendly alternatives to toxic hexavalent chromium (Cr(VI)) conversion layers, as used in the aerospace industry, offering excellent corrosion protection without environmental risks.
EXOCOAT™ AC is a sol-gel hybrid coating that chemically bonds to aluminum surfaces, forming a durable oxide barrier that resists corrosion and aging.
It is specifically engineered to protect aerospace-grade alloys like Alu 2024 and Alu 7075, which are prone to pitting and galvanic corrosion.
When used as a complete system with a sol-gel layer, an epoxy primer and a polyurethane topcoat, EXOCOAT™ AC delivers high durability and strong chemical resistance. It meets the strict requirements of the aviation sector.
This advanced coating system ensures long-term performance and compliance with aerospace norms, supporting safer and more sustainable aircraft manufacturing.
Yachtcare
EXOCOAT™ Ceramic+ Yacht is a cost-effective alternative to spray paint a yacht, offering a high-performance ceramic layer that restores and protects surfaces.
Its unique chemistry forms a transparent, SiO₂-based coating that bonds to any paint system, reviving dull finishes and enhancing gloss.
The coating delivers long-lasting resistance to UV, saltwater, acids, and mechanical wear, passing rigorous ISO tests for marine durability.
It greatly cuts down on dirt accumulation, reducing it by up to 90 % on treated surfaces. This makes cleaning easier and helps maintain the appearance.
With only 10ml needed per m², EXOCOAT™ Ceramic+ Yacht combines efficiency, protection, and ease of application for superior yacht care.
Antigraffiti
EXOCOAT™ Ceramic+ is a true anti-graffiti solution that forms a hard, invisible ceramic layer with low surface energy, making graffiti easy to remove without damaging the surface.
Unlike polyurethane coatings, which are merely solvent-resistant and lack non-stick properties, Ceramic+ actively repels graffiti and dirt through its hydrophobic and oleophobic chemistry.
It passes top international standards (NF31-112 and ASTM D6578) with ratings up to 10, ensuring complete graffiti removal using just water or a dry cloth.
The coating is highly resistant to UV, chemicals, and abrasion, and revives dull surfaces while maintaining long-term durability.
Ideal for public transport, urban infrastructure, and metal cladding, EXOCOAT™ Ceramic+ offers a cost-effective, long-lasting alternative to frequent repainting or surface restoration.
